On the availability bias in narwhal abundance estimates
Keywords:Narwhal, aerial surveys, Greenland, diving behavior, surface time, zero offset correction
Abundance estimation of narwhals is usually done with either visual or photographic aerial surveys. The basic estimation for both methods is detection of whales at the surface, and to obtain fully corrected abundance estimates, the at-surface detections need to be corrected for the proportion of whales that, at any given time, is available to be detected at the surface. The surfacing time or ‘availability correction factor’ is obtained from whales instrumented with dive recorders, that either relay concatenated information on the proportion of time spent at different depth intervals to satellites, or from recovered instruments that collect complete dive profiles, measured at high frequency. Concatenated data binned in depth histograms from Satellite-Linked-Time-Depth-Recorders (SLTDR) falls in two categories, where those that correct the zero depth values with information from the saltwater switch provide larger and apparently more accurate surfacing times, than those collected from instruments that does not correct the zero depth readings. The erroneous detection of near-surface pressure values is likely due to slow response of pressure transducers made from temperature sensitive materials. The high frequency sampling from AcousondeTM recorders documents erroneous surface detections, and adjustments of the dive profiles are needed to obtain realistic near-surface values. Any reconstruction of dive profiles and near-surface values apparently involves some level of corrections and it is recommended, for development of availability correction factors for aerial surveys, that data from zero-adjusted SLTDRs or TDR instruments are used. The mean estimate of surface time from 7 SLTDRs was 29% (CV=0.05). One SLTDR, with steel pressure transducer and zero-adjustments, that was retrieved from the whale, provided a particular long-record (83 days) of reliable high-resolution data. The surface time for this sample was 31%, when calculated as the sum of all depth readings at or above 2 m. The mean of 144 hourly depth readings during 06:00-18:00, and including dives above 3m, was 27.36% (CV=0.8) for 12 days overlapping with the usual timing of aerial surveys. Accurate estimation of smaller depth bins (e.g. 0-1 m) should, even with high resolution instruments, be used with caution when estimating availability bias.
Blackwell, S.B., Tervo, O.M., Conrad, A.S., Sinding, M.H.S., Hansen, R.G., Ditlevsen, S. & Heide-Jørgensen, M.P. (2018). Spatial and temporal patterns of sound production in East Greenland narwhals. PLoS ONE 13(6): e0198295. https://doi.org/10.1371/journal.pone.0198295.
Borchers, D.L., Zucchini, W., Heide-Jørgensen, M.P., Cañadas, A., & Langrock, R. (2013). Using hidden Markov models to deal with availability bias on line transect surveys. Biometrics, https://doi.org/10.1111/biom.12049
Doniol-Valcroze, T. Gosselin, J.-F., Pike, D.G., Lawson, J.W., Asselin, N.C., Hedges, K. & Ferguson, S.H. (2020). Distribution and abundance of the Eastern Canada–West Greenland bowhead whale population based on the 2013 High Arctic Cetacean Survey. NAMMCO Scientific Publications 11. https://doi.org/10.7557/3.5315
Heide-Jørgensen, M.P. & Dietz, R. (1995). Some characteristics of narwhal, Monodon monoceros, diving behaviour in Baffin Bay. Canadian Journal of Zoology 73, 2106-2119.
Heide-Jørgensen, M.P. & Laidre, K.L. (2015). Surfacing time, availability bias and abundance of humpback whales in West Greenland. Journal of Cetacean Research and Management 15: 1-8.
Heide-Jørgensen, M.P., Hammeken, N., Dietz, R., Orr, J. & Richard, P. (2001). Surfacing Times and Dive Rates for Narwhals (Monodon monoceros) and Belugas (Delphinapterus leucas). Arctic 54 (3), 284-298.
Heide-Jørgensen, M.P., Laidre, K.L., Burt, M.L., Borchers, D.L., Marques, T.A., Hansen, R.G., Rasmussen M. & Fossette, S. (2010). Abundance of narwhals (Monodon monoceros L.) on the hunting grounds in Greenland. Mammalogy 91(5), 1135-1151.
Heide-Jørgensen, M.P., Nielsen, N.H., Hansen, R.G., Schmidt, H.C., Blackwell S.B. & Jørgensen, O.A. (2015). The predictable narwhal: satellite tracking shows behavioural similarities between isolated subpopulations. Journal of Zoology 297, 54-65. https://doi.org/10.1111/jzo.12257
Heide-Jørgensen, M.P., Blackwell, S.B., Tervo, O.M., Samson, A.L., Conrad, A.S., Garde, E., … Ditlevsen, S. (2021). Behavioral response study on seismic airgun and vessel exposures in narwhals. Frontiers in Marine Science. https://doi.org/ 10.3389/fmars.2021.658173
Laidre, K.L., Heide-Jørgensen, M.P. & Dietz, R. (2002). Diving behaviour of narwhals (Monodon monoceros) at two coastal localities in the Canadian Arctic. Canadian Journal of Zoology 80: 624-635.
Luque, S.P., and Fried, R. (2011). Recursive Filtering for Zero Offset Correction of Diving Depth Time Series with GNU R Package diveMove. PLoS ONE 6(1): e15850. https://doi.org/10.1371/journal.pone.0015850.
Marsh, H., & Sinclair, D. (1989). Correcting for visibility bias in strip transect aerial surveys of aquatic fauna. Journal of Wildlife Management, 53(4), 1017–1024. https://doi.org/ 10.2307/3809604
NAMMCO-JCNB Joint Working Group (2021). Report of the Joint Working Group Meeting of the NAMMCO Scientific Committee Working Group on the Population Status of Narwhal and Beluga in the North Atlantic and the Canada/Greenland Joint Commission on Conservation and Management of Narwhal and Beluga Scientific Working Group. December 2021, Winnipeg, Canada. Retrieved from https://nammco.no/wp-content/uploads/2022/02/report_jwg_2021.pdf
Ngô, C.M., Heide-Jørgensen, M.P. & Ditlevsen S. (2019). Understanding narwhal diving behaviour using Hidden Markov Models with dependent state distributions and long-range dependence. PloS Computational Biology. https://doi.org/ 10.1371/journal.pcbi.1006425
Richard, P.R., Laake, J.L., Hobbs, R.C., Heide-Jørgensen, M.P., Asselin, N.C. & Cleator, H. (2010). Baffin Bay narwhal population distribution and numbers: aerial surveys in the Canadian High Arctic, 2002-2004. Arctic 63(1), 85–99.
Tervo, O.M., Ditlevsen, S., Ngô, M.C., Nielsen, N.H., Blackwell, S.B., Williams, T.M. and Heide-Jørgensen, M.P. 2021. Hunting by the stroke: How foraging drives diving behavior and swimming biomechanics of East-Greenland narwhals (Monodon monoceros). Frontiers of Marine Science. https://doi.org/10.3389/fmars.2020.596469
Watt, C.A., Marcoux, M., Asselin, N.C., Orr, J.R., & Ferguson, S.H. (2015a). Instantaneous availability bias correction for calculating aerial survey abundance estimates for narwhal (Monodon monoceros) in the Canadian High Arctic. DFO Can. Sci. Advis. Sec. Res. Doc.2015/nnn. vi + xx p. Retrieved from https://publications.gc.ca/collections/collection_2015/mpo-dfo/Fs70-5-2015-044-eng.pdf
Watt, C.A., Orr, J.R., Heide-Jørgensen, M.P., Nielsen, N.H. & Ferguson, N.H. (2015b). Differences in dive behavior among the world’s three narwhal (Monodon monoceros) populations correspond with dietary differences. Marine Ecology Progress Series 525, 273–285. https://doi.org/ 10.3354/meps11202
Watt, C.A., Marcoux, M., Ferguson, S.H., Hammill, M.O. & Matthews, C.J.D. (2021). Population dynamics of the threatened Cumberland Sound beluga (Delphinapterus leucas) population. Arctic Science. 7(2): 545-566. https://doi.org/10.1139/as-2019-0030
Westdal, K.H., Richard, P.R. & Orr, J.R. (2013). Availability bias in population survey of Northern Hudson Bay narwhal (Monodon monoceros). Polar Biology 3, 1235–1241.
